NAKAMURA-TOME WT150
Characteristics - "NAKAMURA-TOME WT150"
| CNC Control: | Fanuc 18i-TB |
| Travel X-axis: | 157.5 mm |
| Travel Y-axis: | +/- 35 mm |
| Travel Z-axis: | 464.8 mm |
| C-axis: | 360º (0.001º increments) |
| Turning length: | 399 mm |
| Max. turning diameter: | ø190 mm |
| Distance between spindle noses: | 750 mm |
| Spindle bore: | 65 mm |
| Upper turret: | |
| Number of tool stations: | 12 |
| Max. speed of driven tools: | 6,000 rpm |
| Driven tool power: | 5.5 / 3.7 kW |
| Lower turret: | |
| Number of tool stations: | 12 |
| Max. speed of driven tools: | 6,000 rpm |
| Driven tool power: | 5.5 / 3.7 kW |
| Main spindle: | |
| Max. spindle speed: | 5,000 rpm |
| Spindle drive power: | 15 / 11 kW |
| Sub spindle: | |
| Max. spindle speed: | 4,500 rpm |
| Spindle drive power: | 11 / 7.5 kW |
| Year of construction: | 2007 |
| Equipment: | |
| Parts catcher | |
| Bar feeder: | LNS HYDROBAR SPRINT |
| Rated power: | 67.2 kVA |
| Basic machine: Dimensions / Weight | |
| Length: | 3,675 mm |
| Width: | 2,258 mm |
| Height: | 1,885 mm |
| Weight: | 9,000 kg |
